Bunk Trailers
Easy to maintain.
Benefits of Bunk Trailers
Bunk Trailers are great for those looking for a low maintenance option that makes it easy to store over time. Bunk trailers are more affordable than roller trailers due to simpler design and fewer moving parts. Most bunk trailers offer drive-on capability since the trailer must be relatively deep in order to launch and load your boat. Our Bunk Trailers are available in both hot dipped galvanized steel or aluminum, shown below.
- Best for boat storage
- Less maintenance required
- Drive-on capability
Standard Features
- LED Lights
- Plug & Play Lights
- Aluminum Diamond Plate Fenders
- D.O.T. Composite Brake Line with Brass Fittings
- Balanced Radial Tires
- Eliminator GalvX Vented Rotor Disc Brakes
- Super Lube Spindles
- Wheel Balancing
- Galvanized Hardware, U-bolts, Winch Stand, Axles, Tongue
- ...and many other components
*Some features are not standard on all models. Please check with your dealer for additional information.
Free of Charge
Tire Change, Towing, Car Lockout, Jump Start, Gas Delivery & Key Replacement. Every boat trailer comes with the Tredit Advantage Program, providing you with nationwide, 24/7 roadside assistance through Urgent.ly, completely free of charge. Enjoy piece of mind with no membership fees, hidden costs, or long wait times. Get upfront estimates and only pay when the service is completely. With Tredit Advantage, you're covered for any roadside emergency. Tredit Advantage WebsiteAluminum Bunk
Aluminum Single Axle Bunks 1025 - 3525 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Tire Size | GVWR | Overall Length | Overall Width | Between Fenders |
| VAB-1025 | 1025 | 12'-14' | 8'6"-13' | Optional | 1 | NO | 4.80 x 12 LRC 5H | 1230 | 15'5 | 60" | 42" |
| VAB-1325 | 1325 | 14'-15' | 8'6"-15'6" | Optional | 1 | NO | 4.80 x 12 LRC 5H | 1535 | 18'1" | 60" | 42" |
| VAB-2025 | 2025 | 16'-17' | 13'-18' | Optional | 1 | NO | ST175/80R 13 LRC 5H | 2485 | 20'3" | 93" | 76" |
| VAB-2425 | 2425 | 16'-18' | 14'-18' | Optional | 1 | Optional | ST185/80R 13 LRD 5H | 2985 | 19'10" | 89" | 71" |
| VAB-2625 | 2625 | 17'-19' | 14'-18' | Optional | 1 | Optional | ST205/75R 14 LRC 5H | 3185 | 19'10" | 89" | 71" |
| VAB-2825 *Pictured | 2825 | 18'-20' | 16'-20' | Optional | 1 | Optional | ST205/75R 14 LRC 5H | 3525 | 22'1" | 100" | 81" |
| VAB-3025 | 3025 | 18'-20' | 16'-20' | Single Wheel | 1 | Disc | ST215/75R 14 LRC 5H | 3725 | 22'10" | 100" | 81" |
| VAB-3325 | 3325 | 20'-22' | 17'6"-21' | Single Wheel | 1 | Disc | ST225/75R 15 LRD 6H | 4100 | 24' | 100" | 81" |
| VAB-3525 | 3525 | 20'-22' | 17'6"-21' | Single Wheel | 1 | Disc | ST225/75R 15 LRD 6H | 4350 | 24' | 100" | 81" |
Aluminum Tandem Axle Bunks 3625 - 8725 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Tire Size | GVWR | Overall Length | Overall Width | Between Fenders |
| VATB-3625 | 3625 | 18'-20' | 16'-20' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 4585 | 22'10'' | 100" | 81" |
| VATB-4225 | 4225 | 21'-22' | 17'6"-21' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 5165 | 24' | 100" | 81" |
| VATB-5225 *Pictured | 5225 | 21'-22' | 17'6"-21' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 6165 | 24' | 100" | 81" |
| VATB-5925 | 5925 | 22'-23' | 17'6"-22' | 2000lb. Foot | 2 | Disc-1 | ST205/75R 14 LRC 5H | 6905 | 25'9" | 100" | 81" |
| VATB-6425 | 6425 | 24'-25' | 19'-24' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 7555 | 27'7" | 100" | 81" |
| VATB-7225 | 7225 | 25'-26' | 19'-24' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 8525 | 27'7" | 100" | 81" |
| VATB-8025 | 8025 | 25'-26' | 21'6"-26' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 9365 | 30'1" | 100" | 81" |
| VATB-8725 | 8725 | 26'-28' | 21'6"-26' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 10085 | 30'9" | 100" | 81" |
| VATB-9325 Torsion Axles | 9325 | 27'-29' | 22'-28' | Flat Foot | 2 | Disc-2 | ST225/75R 15 LRE 6H | 10845 | 31'7" | 101" | 81" |
Aluminum Triple Axle Bunks 9625 - 18025 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Tire Size | GVWR | Overall Length | Overall Width | Between Fenders |
| VATB-9625 | 9625 | 27'-29' | 22'-28' | 2000lb. Foot | 3 | Disc-2 | ST225/75R 15 LRD 6H | 11425 | 31'7" | 100" | 81" |
| VATB-10625 | 10625 | 27'-29' | 22'-28' | 2000lb. Foot | 3 | Disc-2 | ST225/75R 15 LRD 6H | 12425 | 31'7'' | 100" | 81" |
| VATB-12625 | 12625 | 29'-33' | 26'-31' | 2000lb. Foot | 3 | Disc-3 | ST225/75R 15 LRD 6H | 14485 | 37' | 100" | 81" |
| VATB-15025 | 15025 | 32'-36' | 30'-35' | 2000lb. Foot | 3 | Disc-3 | ST235/80R 16 LRE 8H | 17505 | 39'11" | 102" | 82" |
| VATB-18025 *Pictured | 18025 | 32'-36' | 30'-35' | 2000lb. Foot | 3 | Disc-3 | ST235/80R 16 LRE 8H | 19990 | 39'11" | 102" | 82" |
Commander Series (Premium Line)
Aluminum Single Axle Commander Series 2900 - 3400 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Coupler Size | Tire Size | GVWR | Overall Length | Overall Width |
| COM-2900 | 2900 | 18'-20' | 16'-20' | Single Wheel | 1 | NO BRAKES | 2'' | ST205/75R 14 LRC 5H | 3600 | 22'1" | 101'' |
| COM-3100 | 3100 | 18'-20' | 16'-20' | Single Wheel | 1 | Disc-1 | 2'' | ST215/75R 14 LRC 5H | 3800 | 22'10" | 101'' |
| COM-3400 *Pictured | 3400 | 20'-22' | 17'6"-21' | Single Wheel | 1 | Disc-1 | 2'' | ST225/75R 15 LRD 5H | 4175 | 24' | 101'' |
Aluminum Tandem Axle Commander Series 3700 - 8800 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Coupler Size | Tire Size | GVWR | Overall Length | Overall Width |
| COM-3700 | 3700 | 18'-20' | 16'-20' | Single Wheel | 2 | Disc-2 | 2'' | ST205/75R 14 LRC 5H | 4650 | 22'10" | 101'' |
| COM-5300 *Pictured | 5300 | 20'-22' | 17'6'-21' | Single Wheel | 2 | Disc-2 | 2'' | ST205/75R 14 LRC 5H | 6250 | 24' | 101'' |
| COM-6000 | 6000 | 22'-23' | 18'8"-22' | 2000lb Foot Jack | 2 | Disc-2 | 2'' | ST205/75R 14 LRC 5H | 7050 | 24'11" | 101'' |
| COM-6500 | 6500 | 24'-26' | 19"-24' | 2000lb Foot Jack | 2 | Disc-2 | 2'' | ST225/75R 15 LRD 5H | 7800 | 28' | 101'' |
| COM-7300 | 7300 | 24'-26' | 19"-24' | 2000lb Foot Jack | 2 | Disc-2 | 2 5/16'' | ST225/75R 15 LRD 5H | 8600 | 27'7' | 101'' |
| COM-8100 | 8100 | 25'-27' | 21'6"-26" | 2000lb Foot Jack | 2 | Disc-2 | 2 5/16'' | ST225/75R 15 LRD 6H | 9440 | 30'1" | 101'' |
| COM-8800 | 8800 | 26'-28' | 21'6"-27" | 2000lb Foot Jack | 2 | Disc-2 | 2 5/16'' | ST225/75R 15 LRD 6H | 10160 | 30'9" | 101'' |
Aluminum Triple Axle Commander Series 10800 - 12600 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Coupler Size | Tire Size | GVWR | Overall Length | Overall Width |
| COM-10800 *Pictured | 10800 | 27'-29' | 22'-28' | 2000lb Foot Jack | 3 | Disc-3 | 2 5/16'' | ST225/75R 15 LRD 6H | 12730 | 31'7" | 101'' |
| COM-12600 | 12600 | 29'-33' | 26'-31' | 2000lb Foot Jack | 3 | Disc-3 | 2 5/16'' | ST225/75R 15 LRD 6H | 14610 | 37'1" | 101" |
Galvanized Bunk
Galvanized Single Axle Bunks 1000 - 3300 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Tire Size | GVWR | Overall Length | Overall Width | Between Fenders |
| VB-1000 | 1000 | 12'-14' | 8'6"-13' | Optional | 1 | No | 4.80 x 12 LRC 5H | 1270 | 15'9" | 60" | 42" |
| VB-1300 | 1300 | 14'-15' | 8'6"-15'16" | Optional | 1 | No | 4.80 x 12 LRC 5H | 1575 | 17'6" | 60" | 42" |
| VB-1500 | 1500 | 14'-15' | 10'6"-14'6" | Optional | 1 | No | 5.30 x 12 LRC 5H | 1920 | 16'8" | 78" | 60" |
| VB-1800 | 1800 | 15'-16' | 10'6"-16'6" | Optional | 1 | No | 5.30 x 12 LRD 5H | 2230 | 19'2" | 78" | 60" |
| VB-2000 | 2000 | 16'-17' | 14'-16'6" | Optional | 1 | No | ST175/80R 13 LRC 5H | 2550 | 18'6'' | 84" | 67" |
| VB-2200 *Pictured | 2200 | 17'-18' | 14'-17'6" | Optional | 1 | No | ST185/80R 13 LRD 5H | 2750 | 19'4" | 84" | 67" |
| VB-2400 | 2400 | 17'-18.5' | 14'-18'6" | Optional | 1 | No | ST205/75R 14 LRC 5H | 3190 | 20'9" | 88" | 67" |
| VB-2600 | 2600 | 18'-19' | 15'-18' | Optional | 1 | Optional | ST205/75R 14 LRC 5H | 3380 | 21'10" | 100" | 81" |
| VB-2800S | 2800 | 18'-20' | 15'-18' | Optional | 1 | Optional | ST205/75R 15 LRC 5H | 3580 | 21'10" | 100" | 81" |
| VB-2800 | 2800 | 20'-21' | 16'-20' | Optional | 1 | Optional | ST205/75R 15 LRC 5H | 3625 | 22'11" | 100" | 81" |
| VB-3000S | 3000 | 18'-20' | 15'-18' | Single Wheel | 1 | Disc | ST215/75R 14 LRC 5H | 3780 | 22'6" | 100" | 81" |
| VB-3100 | 3100 | 20'-21' | 16'-20' | Single Wheel | 1 | Disc | ST215/75R 14 LRC 5H | 3975 | 22'11" | 100" | 81" |
| VB-3300 | 3300 | 20'-21' | 16'-20' | Single Wheel | 1 | Disc | ST225/75R 15 LRD 6H | 4175 | 23'6" | 100" | 81" |
Galvanized Tandem Axle Bunks 3600 - 7900 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Tire Size | GVWR | Overall Length | Overall Width | Between Fenders |
| VBT-3600S | 3600 | 18'-20' | 15'-19' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 4600 | 22'6" | 100" | 81" |
| VBT-3700 | 3700 | 21'-23' | 17'-21' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 4750 | 25'5" | 100" | 81" |
| VBT-4200 | 4200 | 21'-23' | 17'-21' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 5250 | 25'5" | 100" | 81" |
| VBT-4700 | 4700 | 21'-23' | 17'-21' | Single Wheel | 2 | Disc-1 | ST205/75R 14 LRC 5H | 5750 | 25'5" | 100" | 81" |
| VBT-5200 | 5200 | 21'-23' | 17'-21' | Single Wheel | 2 | Disc-1 | ST205/75R 15 LRC 5H | 6250 | 25'5" | 100" | 81" |
| VBT-5600 | 5600 | 21'-23' | 17'-21' | Single Wheel | 2 | Disc-1 | ST205/75R 15 LRC 5H | 6650 | 25'5" | 100" | 81" |
| VBT-5900 | 5900 | 24'-25' | 19'-24' | 2000lb. Foot | 2 | Disc-1 | ST215/75R 15 LRC 5H | 7300 | 27'6" | 100" | 81" |
| VBT-6400 | 6400 | 25'-26' | 19'-24' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 7825 | 28'11" | 100" | 81" |
| VBT-7400 | 7400 | 25'-27' | 19'-24' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 8825 | 29'10" | 100" | 81" |
| VBT-7900 | 7900 | 25'-27' | 20'-25' | 2000lb. Foot | 2 | Disc-1 | ST225/75R 15 LRD 6H | 9350 | 29'10" | 100" | 81" |
Galvanized Triple Axle Bunks 8600 - 10800 Load Capacity
Swipe to see more.
| Model | Capacity | *Boat Length | Bow Eye to Transom Min/Max | Tongue Jack | # of Axles | Brakes | Tire Size | GVWR | Overall Length | Overall Width | Between Fenders |
| VBT-8600 | 8600 | 27'-28' | 22'-26'6" | 2000lb. Foot | 3 | Disc-2 | ST205/75R 14 LRC 5H | 10420 | 31'6" | 100" | 81" |
| VBT-9200 | 9200 | 28'-30' | 22'-28' | 2000lb. Foot | 3 | Disc-2 | ST225/75R 15 LRD 6H | 11040 | 32'11" | 100" | 81" |
| VBT-10800 | 10800 | 29'-31' | 22'-28' | 2000lb. Foot | 3 | Disc-2 | ST225/75R 15 LRD 6H | 12640 | 32'11" | 100" | 81" |
